Durable Black ESD Antistatic Tray Mold | Industrial PP Plastic Pallets for Electronics Workshop & Laboratory

Product Overview
This specialized injection mold is engineered for manufacturing durable black ESD (electrostatic discharge) antistatic trays using industrial‑grade polypropylene (PP) material. Designed specifically for sensitive electronics workshops, laboratories, and clean‑room environments, it produces trays and pallets that provide reliable electrostatic protection, chemical resistance, and mechanical durability—ensuring safe handling, storage, and transport of static‑sensitive components, devices, and instruments.

Key Features

• ESD‑Safe Material Formulation
  Permanently antistatic PP compound (surface resistivity 10⁶–10⁹ Ω/sq) dissipates static charges continuously without requiring coatings or additives, meeting ANSI/ESD S20.20 and IEC 61340‑5‑1 standards.

• Industrial‑Style Robust Design
  Reinforced rib structures, thick‑wall construction (2.5–4.0 mm), and impact‑resistant corners withstand repeated handling, stacking, and automated transport in high‑cycle workshop and lab environments.

• Chemical & Contamination Resistance
  Black pigmented PP provides inherent resistance to solvents, oils, and common laboratory chemicals, while smooth, non‑particle‑shedding surfaces maintain cleanliness in controlled environments.

• Workshop‑Optimized Functionality
  Features include stackable interlock design, component‑separator slots, barcode/RFID label areas, and optional conductive or dissipative foam inserts for sensitive device cushioning.

• Thermal & Dimensional Stability
  Maintains structural integrity and ESD performance across a temperature range of –40°C to 120°C, suitable for autoclave sterilization, thermal cycling, and cold‑storage applications.

Technical Specifications

• Material: Permanent antistatic polypropylene (PP)

• Surface Resistivity: 10⁶–10⁹ Ω/sq (ASTM D257)

• Load Capacity: 15–30 kg per tray (stackable 8–12 high)

• Wall Thickness: 2.5–4.0 mm (reinforced areas up to 5.0 mm)

• Standard Colors: Black (RAL 9005) or custom ESD‑safe colors

• Temperature Range: –40°C to 120°C

• Compliance: ANSI/ESD S20.20, IEC 61340‑5‑1, FDA‑compliant options

• Production: Multi‑cavity mold with options for separator‑slot inserts and labeling recesses

Applications

• Electronics manufacturing line component handling

• Laboratory sample and instrument storage

• Semiconductor wafer and PCB transport

• Medical device assembly and sterile packaging

• Aerospace and automotive electronic module logistics

Where Protection Meets Precision
This mold creates more than a tray—it delivers an ESD‑secure handling ecosystem for environments where a single static spark can mean costly damage. By uniting permanent antistatic performance with industrial durability, it helps workshops and labs protect sensitive assets, streamline workflows, and maintain integrity—from bench to bay, from cleanroom to cargo.
